JCB 19C-1 Mini Excavator
Delivering conventional tailswing stability in a compact footprint, the JCB 19C-1 mini excavator is built for tight but demanding job sites. Anchored by a 4,034-pound operating weight and a retracting H-frame undercarriage, it easily navigates narrow residential gates before expanding for maximum lifting performance. Powered by a 21.9-horsepower Perkins engine and an 8.4 gpm auxiliary hydraulic system, the 19C-1 pushes 4,047 pounds of bucket breakout force and a 96-inch maximum digging depth, providing the smooth, responsive tearout capabilities needed for utility and landscaping work.
Current Promotions
Current promotions can save you money. We offer promotions that may include Low finance rates, cash back, bonus attachments and more. Check out our current promotional offers to see what may apply to your next equipment purchase.
JCB 19C-1 Specifications
| Operator Protection | ROPS/FOPS |
| Tail Swing Type | Conventional |
| Operating Weight | 4210.8 lb |
| Overall Width | 52.4 in |
| Overall Width (extended) | 52.4 in |
| Overall Height | 92.3 in |
| Overall Length | 152.0 in |
| Horsepower | 14.4 hp |
| Engine Manufacturer | Perkins |
| Engine Model | 403J-11 |
| Emissions Tier | EPA Tier 4 Final |
| Fuel Tank Capacity | 4.9 gal |
| Battery Capacity | 0.78 kWh |
| System Voltage | 12.0 V |
| Maximum Digging Depth | 96.0 in |
| Maximum Reach at Ground Level | 150.0 in |
| Maximum Dumping Height | 110.9 in |
| Bucket Breakout Force | 4047.0 lbf |
| Stick Digging Force - Standard | 2271.0 lbf |
| Blade Size (H x W) | 9.2 in x 52.8 in (with extensions) in |
| Arm Configuration | 37 in Standard Arm (43 in and 53 in options available) |
| Auxiliary Circuit Flow | 8.4 gal/min |
| Track Shoe Type | Rubber (Steel available) |
| Ground Pressure | 4.7 psi |
Specifications and images may vary in accuracy.
